1.Adopting Cummins engine, with strong driving force, low noise, low oil consumption, and more reliable.

2.Adopting energy saving hydraulic system, main hydraulic parts using original world famous brand to guarantee the good quality and work performance. Low energy consumption, fast response speed, precision control, small impact, can keep strong mining capacity and excellent operation efficiency.

3.Using high performance radiator, unobstructed air flow, fast flow speed, good hear dissipation effect, stable working temperature, and long service life.

4.The welding of machine main structures use automatic welding robot, key parts welding flaw detection to ensure all parts in high strength, high quality, and to prolong the service life of the machine.

5.Good vibration and noise effect of the cab, both warm and cool air-conditioner, makes driving comfortable and safe.

总长（Overall Length）	7820mm
功率（Rated Power/speed）	92KW/2200R
总高（Overall Tall）	3370mm
整机宽度（Overall Width）	2780mm
发动机型号（Engine Type）	Cummins QSB3.9
转台宽度（Steering Width）	2560mm
尾部回转半径（Radius, Swing Center to Rear   End）	2430mm
轴距（Wheelbase）	2730mm
轮距（Whell tread）	2030mm
液压系统压力（Hydraulic System Pressure）	31.5Mpa
铲斗容量（Bucket Volume）	0.8m³
回转速度（Rotation Speed）	14r/min
爬坡能力（Gradeability）	≧35%
最大挖掘力（Max. Digging Force）	86KN
最大挖掘半径（Max. Digging Radius）	9000mm
最大挖掘深度（Max. Digging Depth）	5680mm
最大挖掘高度（Max. Digging Height）	9660mm
最大卸载高度（Max. Dumping Height）	6900mm
整机质量（Approximate Weight）	17Ton±10%
轮胎规格（Tyre Type）	1000-20
行走速度（Travel Speed）	35km/h
是否带空调（Air     Condation)	within
旋转度（Rotate）	360º
